Rubber Lined

Industrial Hose

We are dedicated to the manufacture and delivery of the highest quality hose products, combining the best in raw materials with expert craftsmanship.

Lightweight, single jacket construction, combining 100% polyester ring spun staple and filament fibers over a thin wall, high tensile, EPDM rubber liner. The outer jacket is mildew resistant and available with “Key-Lok” polyurethane based polymer impregnation for unmatched abrasion and moisture resistance.

A proprietary reverse twill weave construction reduces friction loss, while high tensile yarn combinations allow hose to be 25% lighter.

Hose features a 5-year warranty, is FM Approved, tested to 600 psi, and UL Listed*.

Features

Specifications

← Slide to view entire chart →

DiameterPart No.Service TestProof TestBurst TestBowl SizeWeight Uncoupled
1"SP10-600300 psi600 psi900 psi1316"0.10 lbs/ft
**1½"SP15-600300 psi600 psi900 psi1¾"0.15 lbs/ft
*2"SP20-600300 psi600 psi900 psi2¼"0.17 lbs/ft
*2½"SP25-600300 psi600 psi900 psi2¾"0.28 lbs/ft

*UL Listed to 250 psi | **UL Listed to 250 psi and FM Approved

Colors

Clear Coat

Red

Orange

Yellow

Green

Blue

Tan

Black

NFPA colors available

Spec Sheet

Download PDF

Warranty

Information

Eco-5 hose has a potential service life and warranty of 5 years, barring mistreatment that would render it unfit for service. Upon delivery, the hose shall be free from defects in materials and workmanship.
