Attack and

Supply Hose

We are dedicated to the manufacture and delivery of the highest quality hose products, combining the best in raw materials with expert craftsmanship.

Lightweight, double jacket construction, combining 100% premium ring spun staple and filament polyester fibers over a thin wall, high tensile, EPDM rubber liner. The outer jacket is mildew and moisture resistant, available with “Key-Lok” polyurethane based polymer impregnation which shall meet the requirements of MIL‑H‑24606 latest edition for abrasion resistance.

A proprietary reverse twill weave construction reduces friction loss, while engineered yarn selections lighten the hose up to 25% compared to competitive offerings.

This reliable, impregnated double jacket fire hose is tested to 600 and 800 psi, meets MIL‑H‑24606 latest edition for abrasion resistance and is UL Listed* and FM Approved.

Features a 10-year warranty and lifetime liner delamination guarantee.



← Slide to view entire chart →

DiameterPart No.Service TestProof TestBurst TestBowl SizeWeight Uncoupled
1"DP10-800400 psi800 psi1200 psi138"0.14 lbs/ft
**1½"DP15-800-ECO400 psi800 psi1200 psi11516"0.23 lbs/ft
*1¾"DP17-800-ECO400 psi800 psi1200 psi2116"0.28 lbs/ft
*2"DP20-800400 psi800 psi1200 psi225"0.31 lbs/ft
**2½"DP25-800-ECO400 psi800 psi1200 psi3"0.42 lbs/ft
*3"DP30-800-ECO400 psi800 psi1200 psi338"0.56 lbs/ft
4"DP40-600300 psi600 psi900 psi4½"0.82 lbs/ft
5"DP50-600300 psi600 psi900 psi5½"1.14 lbs/ft

*UL Listed to 400 psi | **UL Listed to 400 psi and FM Approved


Clear Coat








NFPA colors available

Spec Sheet

Download PDF



Eco-10 hose has a potential service life and warranty of 10 years with a lifetime warranty against liner delamination, barring mistreatment that would render it unfit for service. Upon delivery, the hose shall be free from defects in materials and workmanship.
